Webinar on Advance and Compact Hygienic Condensers for API Industry

Alfa Laval range of compact welded heat exchanger/ condensers include

Spiral Heat Exchangers (SHEs) – We have supplied several thousand SHES to Indian as well as overseas API Industries. This we supply for SS Reactors. Benefits are as given below

  • Generally, Heat Transfer Area required is ½, compared to Shell and Tube. K values are between 700 to 1400.
  • 100 % Drain ability on the vapour side.
  • More than 98% Solvent recovery in primary condenser itself, due to close temperature approach possible
  • Venting of non-condensable is effective
  • All contact parts of vapours side as well as coolant side in SS 316 L
  • Compact in size – required less area as well less installation cost. Easy to install.
  • Totally gasket free. So, no Maintenance cost
  • Vapour side is 100% visually inspectable.
  • CIP able, Backflush cleanable.

Compabloc - We have supplied several Compablocs to Indian as well as overseas API Industries. This, we supply for Glass line Reactor in Hastelloy as well other exotic MOC. Benefits as below

  •  The Heat Transfer Area required ¼ th compared to Shell and Tube. K values between 1500 to 2200.
  • 100 % Drain ability
  • More than 98% Solvent recovery in Primary condenser itself due to close temperature approach possible
  • Venting of non-condensable is effective
  • All contact parts of vapours side as well as coolant side in Hastelloy or Exotic MOC
  • Compact in size – Required less area as well as less installation cost
  • Totally gasket free. So, no Maintenance cost
  • Both sides are possible to clean mechanically in case required
  • Very low head space is required as it is very compact compared to any other technology

Visit the Compabloc page

Please note that the efficiency of Condensation here is more than 98% in Primary Condenser itself, hence there is the possibility to avoid secondary condensers, which will save CAPEX as well as OPEX.
